| Brand Name : | Yade |
| Model Number : | 1JB-04WD |
| Price : | be negotiation |
Jic Male / Bsp Male Captive Seal Tube Adapter (1JB-WD) <
| Item No.: | Thread | CAPTIVE | Dimension | ||||
| E | F | F END | A | B | L | S1 | |
| 1JB-04WD | 7/16"*20 | G1/4"*19 | WD-B04 | 14 | 12 | 34 | 19 |
| 1JB-04-02WD | 7/16"*20 | G1/8"*28 | WD-B02 | 14 | 8 | 29.5 | 14 |
| 1JB-04-06WD | 7/16"*20 | G3/8"*19 | WD-B06 | 14 | 12 | 34.5 | 22 |
| 1JB-04-08WD | 7/16"*20 | G1/2"*14 | WD-B08 | 14 | 14 | 41 | 27 |
| 1JB-05-04WD | 1/2"*20 | G1/4"*19 | WD-B04 | 14 | 12 | 34 | 19 |
| 1JB-05-06WD | 1/2"*20 | G3/8"*19 | WD-B06 | 14 | 12 | 34.5 | 22 |
| 1JB-06WD | 9/16"*18 | G3/8"*19 | WD-B06 | 14.1 | 12 | 34.5 | 22 |
| 1JB-06-02WD | 9/16"*18 | G1/8"*28 | WD-B02 | 14.1 | 8 | 29.5 | 17 |
| 1JB-06-04WD | 9/16"*18 | G1/4"*19 | WD-B04 | 14.1 | 12 | 34 | 19 |
| 1JB-06-08WD | 9/16"*18 | G1/2"*14 | WD-B08 | 14.1 | 14 | 41 | 27 |
| 1JB-08WD | 3/4"*16 | G1/2"*14 | WD-B08 | 16.7 | 14 | 43.5 | 27 |
| 1JB-08-04WD | 3/4"*16 | G1/4"*19 | WD-B04 | 16.7 | 12 | 37 | 22 |
| 1JB-08-06WD | 3/4"*16 | G3/8"*19 | WD-B06 | 16.7 | 12 | 37.5 | 22 |
| 1JB-08-12WD | 3/4"*16 | G3/4"*14 | WD-B12 | 16.7 | 16 | 45 | 32 |
| 1JB-10-06WD | 7/8"*14 | G3/8"*19 | WD-B06 | 19.3 | 12 | 41.5 | 24 |
| 1JB-10-08WD | 7/8"*14 | G1/2"*14 | WD-B08 | 19.3 | 14 | 46.5 | 27 |
| 1JB-10-12WD | 7/8"*14 | G3/4"*14 | WD-B12 | 19.3 | 16 | 47.5 | 32 |
| 1JB-12WD | 1.1/16"*12 | G3/4"*14 | WD-B12 | 21.9 | 16 | 50 | 32 |
| 1JB-12-06WD | 1.1/16"*12 | G3/8"*19 | WD-B06 | 21.9 | 12 | 46 | 30 |
| 1JB-12-08WD | 1.1/16"*12 | G1/2"*14 | WD-B08 | 21.9 | 14 | 48.5 | 30 |
| 1JB-12-16WD | 1.1/16"*12 | G1"*11 | WD-B16 | 21.9 | 18 | 56 | 41 |
| 1JB-12-20WD | 1.1/16"*12 | G1.1/4"*11 | WD-B20 | 21.9 | 20 | 60 | 50 |
Jic Male / Bsp Male Captive Seal Tube Adapter (1JB-WD)---Our Factory is specialized in makingHydraulic Fittings, Hydraulic Hose Fittings, Hose Fititngs, Hydraulic Adapters, Hydraulic Adaptors and so on.
1) FERRULE
FERRULE for SAE100R1AT/EN 853 1SN HOSE
FERRULE for SAE100R1A EN 853 1ST HOSE
FERRULE for SAE100R2AT/DIN20022 2SN HOSE
FERRULE for SAE100R2A/EN853 2SN HOSE
FERRULE for SAE100R1AT-R2AT,EN853 1SN-2SN and EN 857 2SC
FERRULE for 4SP, 4SH/10-16, R12/06-16 HOSE
FERRULE for 4SH, R12/32 HOSE
2) SWAGED METRIC FITTINGS
Metric Flat Seal Fittings Metric Multiseal Fittings
Metric 60°Cone Seal Fittings Metric 74°Cone Seal Fittings
Metric 24°Cone O-RING Seal L..T. Fittings Metric 24°Cone O-RING Seal H.T. Fittings
Metric Standpipe Straight Fittings JIS Metric 60°Cone Seal Fittings
3) SWAGED BRITISH FITTINGS
BSP O-RING Seal Fittings BSP Flat Seal Fittings
BSP Multiseal Fittings BSP 60°Cone Seal Fittings
BSPT Fittings JIS BSP 60°Cone Seal Fittings
4) SWAGED AMERICAN FITTINGS
SAE O-RING Seal Fittings ORFS Flat Seal Fittings
NPSM 60°Cone Seal Fittings JIC 74°Cone Seal Fittings
NPT Fittings SAE Flange L.T. Fittings SAE Flange H.T. Fittings
5) STAPLELOK FITTINGS
BANJO DOUBLE CONNECTION INTERLOCK HOSE FITTINGS
6) METRIC ADAPTERS
Metric Thread O-RING Face Seal Adapters
Metric Thread Bite Type Tube Adapters
Metric Thread 74°Cone Flared Tube Adapters
JIS Metric Thread 60°Cone Adapters
7) BRITISH ADAPTERS
BSP Thread 60°Cone Adapters
JIS BSP Thread 60°Cone Adapters
BSPT Thread Adapters
8) AMERICAN ADAPTERS
ORFS ADAPTERS JIC 74°Cone Flared Tube Adapters
NPT Thread Adapters
9) OTHER ADAPTERS
Our QC procedure:
As we had more than 5 professional and technical personal, they
ensure 100% products checking.
1. Material checking: strictly control of material using, meet
international requested standards;
2. semi-finished products inspection: product inspection before
100% finished ;
3. production line test: with work team or data engineer who will
inspect machines and lines at fixed period.
4. finished product inspection: quality and property test before products are plated
zinc, packed and loaded.
Shipping & Service:
1. Orders will be dispatched around in 30 days after payment,
depending on quantities.
2. We Always choose the most economical and reliable shipping
company to make sure you receive the goods in time.
3. The tracking number will be provided to you once the consignment
is shipped
4. Professional customer service to answer your questions or fix
problems regarding your order.
Packaging Details Package of HYDRAULIC HOSE FITTINGS:carton boxes and plywood case
Delivery Time We delivery HYDRAULIC HOSE FITTINGS within 10 days
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shipment.
